LINKSCAN 5MP 16mm C-Mount FA Machine Vision Lens F1.6-C Manual Focus

Product Overview

2/3 5MP 16mm FA Lens is a machine-vision FA lens intended for industrial imaging systems that need controlled, repeatable optical performance. The supplied product information identifies a 5MP design for a 2/3 inch image format, with a 16mm focal length and a C-mount interface. Its F1.6-C aperture range gives engineers a practical adjustment range when balancing exposure, depth of field and lighting conditions. The listed manual focus arrangement supports setup around the actual working distance, target size and camera position. Optical glass and aluminium-alloy construction are specified, providing a suitable material combination for use in machine-vision equipment.

In an automated inspection system, the lens is the optical link between the scene and the camera sensor. Selection should consider field of view, pixel coverage, working distance, illumination angle and the surface character of the part being inspected. The supplied specification lists distortion at <0.1%, a nearest working distance of 100mm, and a M27 x 0.5 filter thread. These values provide useful starting points for an optical layout, but final image quality should be verified with the selected camera and real sample parts. Manual adjustment during commissioning can help establish focus and aperture settings that give stable contrast, sharp edges and reliable feature recognition.

This 16mm lens is suitable for component inspection, positioning, code reading and general automation vision stations. It can be integrated with industrial cameras, LED illumination, camera mounts and production fixtures in assembly, sorting, measurement and traceability applications. The C-mount connection helps simplify integration with compatible machine-vision cameras. For dependable results, confirm the sensor format, mechanical clearance, viewing angle, exposure time, lighting and environmental conditions before final installation. Keep the optical path clean and secure the lens after adjustment so focus and aperture settings are not disturbed by vibration or routine machine operation. The supplied data should be used as the engineering reference for model selection and final acceptance testing.

Key Advantages

· 5MP optical configuration for detailed machine-vision imaging with a 2/3 inch format.

· C-mount interface and manual focus support practical integration and commissioning.

· F1.6-C aperture range and listed distortion of <0.1% support optical setup planning.

· Optical glass and aluminium-alloy construction are specified for machine-vision equipment use.

Technical Parameters

Model List

Application Scenarios

This product can be used for component inspection, positioning, code reading and general automation vision stations. It is suitable for machine vision inspection, automated production lines, positioning, code reading, measurement and traceability projects. Final selection should be confirmed with the actual camera, sensor format, workpiece, working distance, field of view, lighting and installation space.
